Luminor RL-470 Replacement UV Lamp for LB4-061, LB5-061, LB6-061

Name: Luminor RL-470 Replacement UV Lamp for LB4-061, LB5-061, LB6-061
Brand: Luminor
SKU: RL-470
Price: 97.23 USD
Availability: InStock
Rating: 5 (3 reviews)

Q&As

Luminor RL-470 replacement UV lamp with lamp key for BLACKCOMB LB4-061, LB5-061, LB6-061 systems

Q&As

Part Number: RL-470

Replacement UV lamp with reset key restores 9000 hour output for Luminor LB4 061 LB5 061 and LB6 061 systems. Read More

$97.23

$121.54

IN STOCK

Receive a 15% bulk discount on orders of 12 or more

Description

The RL-470 is a genuine Luminor replacement UV lamp and lamp key for LUMINOR BLACKCOMB LB4-061, LB5-061, and LB6-061 UV water treatment systems, and their NSF Class A/B and LBV variants listed below. It is an authentic Luminor part, not a compatible aftermarket substitute, so it drops in and treats water the way your system was originally tested and certified to perform.

The lamp is rated for 9,000 hours of use, about 12 months of continuous operation. UV-C output weakens gradually over the lamp's life, so Luminor recommends replacing it every 12 months to keep UV output where the system needs it.

Why a genuine Luminor lamp matters
Luminor tests and certifies its UV systems as a complete unit: lamp, chamber, and sleeve together. An authentic RL-470 keeps your system performing the way it was certified. A non-Luminor lamp voids the system's NSF/ANSI 55 certification and can affect your warranty coverage if a problem comes up later.

Fits these Luminor BLACKCOMB systems

LB4-061
LB5-061
LB6-061
LB5-061B (NSF Class B, non-monitored)
LB6-061B (NSF Class B, non-monitored)
LB6-061A (NSF Class A, monitored, includes UV sensor)
LBV-061

The A and B suffixes mark the system's NSF/ANSI 55 monitoring class (A is monitored with a UV sensor, B is non-monitored), not a different lamp. All seven models above share the same "-061" flow rating and use the RL-470.

Complete your replacement
The RL-470 is the lamp only. For the full replacement:

Luminor RQ-470 Replacement UV Quartz Sleeve, the quartz sleeve that houses the lamp. Replace every 24 months, or sooner if it's visibly scaled, cloudy, or damaged.
Luminor RLQ-470 UV Lamp and Sleeve Kit, which bundles the RL-470 lamp, RQ-470 sleeve, and lamp key together for LB4-061, LB5-061, and LB6-061.

Specs

Replace every 12 months or 9,000 hours of use
Length: 18.5" (470mm)
Power: 22 Watts

Features

Includes Lamp Key (works for LUMINOR Branded Systems Only)

For all LUMINOR BLACKCOMB 4.1 LB4-061, 5.1 LB5-061, 6.1 LB6-061 models

Genuine Luminor OEM lamp, not a generic replacement

This Item Fits These Select Systems

Helpful Info & Downloads

Downloads

Watch this step-by-step video to learn how to replace a quartz sleeve on a Luminor UV water treatment system for optimal UV disinfection performance. ESP Water Products, an authorized Luminor dealer, offers genuine Luminor UV systems and replacement parts.

Overall rating: 5.0 / 5 from 4 reviews.

AI Generated Review Summary

Summary topics

Review topics: [].

Review highlights

Reviews

Exactly Right

"The lamp arrived on time, very well-packaged, and worked perfectly as soon as we installed it. It was easy enough to do that I installed it myself instead of waiting for the plumber we hired. It would be nice if there was a warning on the package (say, on the tube) to only touch the base of the lamp and not the glass. I pulled the lamp out, and it was intuitive to grab the glass to do so. That meant I needed to clean it carefully before install. Maybe you can learn from my mistake."

— Hope M. (5/5)

replacement lamp

"fit well - easy to install - easy to reset timer"

— Guido M. (5/5)

Quick Shipment

"This bulb was needed by one of our customers, but difficult to find. ESP had availability and shipped quickly."

— Jerry M. (5/5)

Excellent service

"Excellent service"

— Peter H. (5/5)

Q&A

Overall rating: 5.0 / 5 from 4 reviews.

AI Generated Review Summary

Summary topics

Review topics: [].

Review highlights

Reviews

Exactly Right

— Hope M. (5/5)

replacement lamp

"fit well - easy to install - easy to reset timer"

— Guido M. (5/5)

Quick Shipment

"This bulb was needed by one of our customers, but difficult to find. ESP had availability and shipped quickly."

— Jerry M. (5/5)

Excellent service

"Excellent service"

— Peter H. (5/5)

Q&A

Q:
How do I know if the RL-470 is the right lamp for my system?

Check the model number on your system's nameplate. The RL-470 fits any Luminor BLACKCOMB system ending in "-061": LB4-061, LB5-061, LB6-061, LB5-061B, LB6-061B, LB6-061A, and LBV-061. If your model ends in a different number, like -021, -031, or -101, you need a different lamp.

Q:
My system is showing a "Lamp Expired" alarm. What does that mean?

t means the lamp has reached the end of its rated life, or a new lamp was installed but the countdown timer on the controller was never reset. Luminor's guidance is that water may not be adequately treated once a lamp has expired, so replace the lamp and reset the timer as soon as possible. Holding the controller button for 5 seconds defers the alarm for 7 days, up to three times, but this doesn't restore UV treatment in the meantime.

Q:
What does a "Lamp Failure" alarm mean?

It means the controller can't light the lamp. Unplug the system for at least 3 minutes, check that the lamp connector is fully seated, then plug it back in. If the alarm continues, replace the lamp. If a new lamp doesn't clear it, the controller itself may need service.

Q:
I installed a new RL-470 and now the system says "Lamp Incorrect." What's wrong?

This alarm means the lamp key doesn't match what your chamber requires. Compare the part number on the lamp key to the silver label on the UV chamber. If they don't match, you have the wrong lamp; the RL-470 is for the standard-output LB4/LB5/LB6-061 systems listed above, and BLACKCOMB-HO systems use an entirely different model and lamp lineup. If the numbers do match and the alarm persists, contact Luminor support.

Q:
How do I reset the lamp timer after installing the RL-470?

On a 4.1 controller (4-digit LED display), press and hold the front button until the display cycles through rSt3, rSt2, rSt1 and beeps. On a 5.1 controller (LCD display with lamp key), unplug the controller, remove the old lamp key, insert the new lamp's key, then plug it back in. Either way, the display should return to showing full lamp life remaining; if it doesn't, contact Luminor support.

Q:
Will a non-Luminor replacement lamp work in my BLACKCOMB system?

It may physically fit, but Luminor systems are NSF/ANSI 55 certified as a complete lamp-and-system unit. A non-Luminor lamp voids that certification and can affect your warranty if an issue comes up.
