Article Summary: A replacement lamp can look similar and still be the wrong part. Genuine LUMINOR components give you a manufacturer-published part number, the correct lamp key where required, model-specific lamp and sleeve matching, and the component specified for applicable NSF/ANSI 55 configurations.
Why Buy Genuine LUMINOR UV Lamps &
Replacement Parts?
Do I Need to Buy a Genuine LUMINOR UV Lamp?
When it is time to replace the UV lamp, quartz sleeve, sensor or another component in your LUMINOR system, it can be tempting to choose a part based on appearance, lamp length or price. The better starting point is the model number on your UV chamber.
LUMINOR publishes exact replacement parts for BLACKCOMB, BLACKCOMB-HO and RAINIER series. Matching the system model to the specified part helps ensure the replacement you order is designed for the system you already own.
See LUMINOR’s replacement-parts information.
Model-specific fit
Part numbers are tied to exact LUMINOR models.
Lamp key where required
Applicable BLACKCOMB systems use LIGHTLOCK.
Published service life
Follow the lamp life specified for your series.
Matched components
Lamp and sleeve combinations are model-specific.
What Makes a Genuine LUMINOR Lamp Different?
LUMINOR states that its replacement lamps use a proprietary internal coating designed to provide consistent UV output across the rated lamp life. The important point for the shopper is simple: visible light is not a measurement of UV performance.
A lamp can still glow while UV output has declined
Do not wait for the lamp to go dark. Replace it according to the service interval specified for your exact LUMINOR series.
Rated Lamp Life by LUMINOR Series
Manufacturer-published rated lamp life
BLACKCOMB
9,000 h
BLACKCOMB-HO
10,000 h
RAINIER
12,000 h
LIGHTLOCK™: Why the Small Lamp Key Matters
On applicable BLACKCOMB 5.1 and 6.1 controllers, LUMINOR's LIGHTLOCK system uses an encrypted lamp key. The controller can identify a missing or incorrect key and can display lamp-key or incorrect-lamp messages.
Private-brand controller? Review LUMINOR’s lamp-key compatibility guidance.
Not sure which LUMINOR lamp you need?
Start with the model number on your UV chamber.
Why the Exact LUMINOR Part Number Matters
Two lamps can look similar while being intended for different systems. Use the links below to find the manufacturer-specified lamp and sleeve for your system model.
Which LUMINOR Lamp and Quartz Sleeve Fit My
System?
The model number on the stainless chamber is the best starting point. Find your system family below, then select its matching lamp or quartz sleeve. Check your exact model and any suffix against the product compatibility list before ordering.
| System Family | Genuine Lamp | Quartz Sleeve | Rated Lamp Life |
| LB4/5/6-021 | 9,000 h | ||
| LB4/5/6-031 | 9,000 h | ||
| LB4/5/6-061 | 9,000 h | ||
| LB4/5/6-101 | 9,000 h | ||
| LB4/5/6-151 | 9,000 h | ||
| LB4/5/6-201 | 9,000 h | ||
| LBH4/5/6-051 | 10,000 h | ||
| LBH4/5/6-101 | 10,000 h | ||
| LBH4/5/6-151 | 10,000 h | ||
| LBH4/5/6-251 | 10,000 h | ||
| LBH4/5/6-401 | 10,000 h |
Luminor RL-820 Replacement UV Lamp for LB4-101, LB5-101, LB6-101
The RL-820 is a genuine Luminor replacement UV lamp and lamp key for LUMINOR BLACKCOMB LB4-101, LB5-101, and LB6-101 UV water treatment systems
- Perfect add-on to a food storage program or 72-hour kit
Luminor RL-470 Replacement UV Lamp for LB4-061, LB5-061, LB6-061
Replacement UV lamp with reset key restores 9000 hour output for Luminor LB4 061 LB5 061 and LB6 061 systems.
- Perfect add-on to a food storage program or 72-hour kit
Luminor RL-999 Replacement UV Lamp for LB4-151, LB5-151, LB6-151
Replacement UV lamp with reset key restores 9000 hour output for LB4 151 and LB5 151 whole home systems
- Perfect add-on to a food storage program or 72-hour kit
Shop Genuine LUMINOR UV Lamps
Standard output, High Output and lamp + sleeve kits.
What About LUMINOR Systems Certified to NSF/ANSI
55?
Some LUMINOR BLACKCOMB and BLACKCOMB-HO models are certified to NSF/ANSI 55 Class A or Class B. For those models, use the configuration specified for the exact system.
Read NSF’s explanation of NSF/ANSI 55 Class A and Class B.
Warranty Is Another Reason to Use the Correct Part
LUMINOR’s limited warranty excludes damage caused by parts that are not compatible, suitable, or authorized for the product, including non-original lamps or sleeves. Read LUMINOR’s warranty terms and exclusions.
10-year reactor
Limited coverage for applicable stainless reactors.
3-year electronics
Limited coverage for applicable controllers/electronics.
1-year parts
Applicable lamps, UV sensors and quartz sleeves.
Correct component
Start with the manufacturer-specified part number.
LUMINOR Replacement Part FAQs
Can I choose a LUMINOR lamp by length alone?
No. Use the UV system model and manufacturer-specified part number. Similar dimensions do not prove fit.
What is the black key included with many LUMINOR lamps?
It is the lamp key used by applicable BLACKCOMB 5.1 and 6.1 LIGHTLOCK controllers.
Which lamp fits a LUMINOR LB5-101?
The LB5-101 uses the RL-820 lamp and RQ-820 sleeve. Select the matching part number in the table above to view product details.
How often should I replace a LUMINOR lamp?
Follow the schedule for the exact series and model. Standard BLACKCOMB lamps are rated at 9,000 hours and BLACKCOMB-HO at 10,000 hours.
